Description

Basic configuration:
-  Base made of high quality stainless steel (raw material 1.4301)
-  Column made of high quality stainless steel (raw material 1.4301)
-  Driveabillity (2 x leading wheels / 4 x fixed castors for heavy loads) with central brake
-  Hand switch with coloured display for electro-hydraulically functions
-  Additional operating panel for electro-hydraulically  functions at the column
-  Additional joystick to drive longitudinal and transversal shift
-  Table top made of carbon-fiber, completely X-ray permeable
-  Longitudinal shift of table top
-  Transversal shift of table top
-  Side rails, also at the head side, made of carbon-fiber for attachment of accessories
-  Frontal side rails for attaching head rest components (skull clamp etc.)
-  Surfaces are easy to clean
-  Upholstery 20 mm thick, electrically conductive
-  Mains operation 110V or 220V / 50-60 Hz
-  Battery and indicator of current charge of battery
-  Continous X-ray permeable carbon fibre lying area: 1300 mm
-  Measurements of the lying area: 2340 x 500 mm
-  Width of the table top incl. side rails: 530 mm
-  AL- equivalece factor: 1,4 mm, 100 kv
-  Loading capacity: up to 250 kg
-  Table weight: approx. 200 kg

Features:
-  Height adjustment from 740 to 1100 mm
-  Trendelenburg and reverse-Trendelenburg: 25° to each side
-  Lateral tilt: up to 20° to each side
-  Longitudinal shift: 300 mm
-  Transversal shift: 180 mm
